TL-PA7017 KIT uses HomePlug AV2 technology to extend your wired internet. With Gigabit Ethernet port, it ensures high speed wired connection, providing data transmissions of up to 10000Mbps and allowing smooth transmission of Ultra HD video streaming
This makes the TL-PA7017 KIT the perfect home entertainment companion.
HARDWARE FEATURES Plug Type
EU, UK, US Standards and Protocols
HomePlug AV2, HomePlug AV, IEEE 1901, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab Interface
Gigabit Ethernet Port Button
Pair/Reset button Power Consumption
Maximum: 2.7W (220V/50Hz)
Typical: 2.3W (220V/50Hz)
Standby: 0.5W (220V/50Hz) LED Indicator
PWR, PLC, ETH Range
300 Meters over electrical circuit SOFTWARE FEATURES Modulation Technology
OFDM (PLC) Encryption
Powerline Security: 128-bit AES OTHERS Certification
CE, RoHS Package Contents
Powerline Ethernet Adapter
6.5 ft. (2 m) Ethernet cable (RJ45)
Quick Installation Guide System Requirements
Windows 2000/XP/2003/Vista, Windows 7/8/8.1, Mac, Linux Environment
Operating Temperature: 0oC to 40oC (32oF to 104oF)
Storage Temperature: -40oC to 70oC (-40oF to 158oF)
Operating Humidity: 10% to 90% non-condensing
Storage Humidity: 5% to 90% non-condensing Item Dimension (L inchxW inchxH inch)
8 x 6 x 4
Weight
2.00 lb
Warranty Information
2 years
AV1000 GIGABIT POWERLINE STARTER KIT
