Specifications

• Mfr Part Number: SSG-2027R-E1R24L
• Motherboard: Super X9DRD-7LN4F-JBOD
• Processor: Dual LGA2011
  • Support Intel Xeon E5-2600 and E5-2600 v2 Family Processor
  • Cache up to 30MB
  • QPI up to 8 GT/s
  • Support up to 130W TDP
• Chipset: Intel C602J
• Memory: 16x 240pin DDR3-1866/ 1600/ 1333/ 1066/ 800 DIMM Slots, Supports up to 1TB ECC/Load Reduced Memory or up to 512GB ECC/REG Memory or 128GB ECC Unbuffered Memory
• Slots: 5x PCI-Express 3.0 x8 Slots (Low-profile)
• SATA: 2x SATA3 Ports, 4x SATA2 Ports, Support RAID 0, 1, 5, 10
• SAS: 8x SAS2 Ports
• Video: Matrox G200eW Graphics
• LAN: Intel i350 Gigabit Ethernet Controller; 1x Realtek RTL8201N PHY (dedicated IPMI)
• Drive Bays: 24x 2.5" Hot-swap SAS/SATA HDD Bays; 2x Rear 2.5" Hot-swap Drive Bays
• Backplane: SAS2/SATA3 Single Expander per Backplane
• Ports: 9x USB 2.0 Ports (4 rear, 4 via headers, 1 Type A), 1x VGA Port, 2x Serial Ports (1 rear, 1 via header), 4x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
• Form Factor: 2U Rackmount
• Power Supply: 920W 80 PLUS Platinum Certified High-efficiency (94%+) AC-DC Redundant Power Supplies w/ PMBus and I2C
• System Cooling: 3x 8cm 9.5K RPM, 4-pin PWM Fans
• Front Panel:
  • Buttons: Power On/Off, System Reset
  • LEDs: Power Status, Hard Drive Activity, 2x Network Activity, System Overheat, Power Fail
• Color: Black
• Dimensions (WxDxH): 17.2 x 24.8 x 3.5 inch / 437.0 x 630.0 x 89.0 mm
• Gross Weight: 61.0 lbs / 27.7 kg
• RoHS Compliant
