General Information

---

Manufacturer:Schneider Electric SA
Manufacturer Part Number:SRT8KRMXLT
Manufacturer Website Address:http://www.schneider-electric.com
Brand Name:APC by Schneider Electric
Product Line:Smart-UPS On-Line
Product Name:Smart-UPS SRT 8000VA RM 208V
Marketing Information:

A versatile UPS developed for the harshest power conditions in the world.
Smart-UPS On-Line provides high density, true double-conversion on-line power protection for servers, voice / data networks, medical labs, and light industrial applications. Capable of supporting loads from 1 to 20kVA in a rack/tower convertible form, the Smart-UPS On-Line is available from 2U to 12U. Recent family extensions at 15 and 20kVA enable support of power hungry blade servers or heavily loaded equipment racks. When business-critical systems require runtime in hours, not minutes, Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The included PowerChute management software provides unattended graceful shutdown of network operating systems. All models 5kVA and above include an integrated Network Management Card for remote management (optional on models below 5 kVA). The Smart-UPS On-Line family provides customers with a reliable source of uninterruptible power even in demanding power environments, including very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.

Product Type:Double Conversion Online UPS

Technical Information

---

Receptacle Type:

• Hard Wire 3-wire (2PH + G)
• NEMA L6-20R
• NEMA L6-30R

Receptacle Detail:

• 1 x Hard Wire 3-wire (2PH + G)
• 4 x NEMA L6-20R
• 2 x NEMA L6-30R

Power Description

---

Load Capacity:8000 VA/8000 W
Input Voltage:208 V AC
Output Voltage:208 V AC
Waveform Type:Sine Wave

Battery Information

---

Battery Chemistry:Lead Acid
Backup/Run Time (Full Load):5 Minute
Typical Battery Recharge Time:1.50 Hour

Physical Characteristics

---

Product Color:Black
Height:10.4"
Width:17"
Depth:28.2"
Rack Height:6U
Form Factor:Rack-mountable
Weight (Approximate):246 lb

Miscellaneous

---

Package Contents:

Smart-UPS SRT 8000VA RM 208V

CD with software

Documentation CD

Installation guide

Rack mounting brackets

Rack mounting hardware

Rack mounting support rails

Temperature probe

USB cable

Warranty card

Web/SNMP management card

Energy Star:Yes
Environmentally Friendly:Yes
Environmental Certification:

• RoHS
• REACH
• ENERGY STAR

Warranty

---

Limited Warranty:3 Year
