StarTech.com MSA Uncoded SFP+ Transceiver Module - 10GBASE-BX - 10 GbE Gigabit Ethernet BiDi Fiber (SMF) - MSA Uncoded Transceiver - 10GBASE-BX WDM SFP+ (10 Gbps) - 10 Gigabit BiDi Module - 1270nmTx/1330nmRx Single Mode (SMF) - 10km (6.2mi) - LC Connector & DDM - Hot-Swappable / MSA Compliant - Lifetime Warranty

MFG No: SFP10GBBXUST
SKU No: TIXDYR7L7A
UPC: 065030873406
MFG. Name: STARTECH
Available: 3
Condition: New

$118.41


This 10GBase-BX (upstream) SFP+ module delivers what you need most in your network connections: reliable performance. It?s built to exacting MSA specifications and fully tested to ensure seamless compatibility. The single-mode SFP+ transceiver module offers a cost-effective way to add, replace or upgrade the ports on your networking equipment, and it?s backed by a lifetime warranty.

General Information
Manufacturer:StarTech.com
Manufacturer Part Number:SFP10GBBXUST
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:SFP+ Module
Marketing Information:

The SFP10GBBXUST is an MSA compliant upstream fiber SFP transceiver which pairs with StarTech.com's SFP10GBBXDST. They are designed, programmed and tested to work with 10GBASE-BX compatible MSA switches and routers. The SFP+ transceiver module supports a maximum distance of up to 10 km (6.2 mi) and delivers dependable 10 GbE connectivity over fiber cabling.

Technical Specifications:
  • Wavelength: 1270nmTx/1330nmRx
  • Maximum Data Transfer Rate: 10 Gbps
  • Type: Single Mode Fiber
  • Connection Type: LC Connector
  • Maximum Transfer Distance: 10 km (6.2 mi)
  • Power Consumption: Less than 1 Watt
  • DDM: Yes

This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.


Packaged Quantity:1
Product Type:SFP+
Technical Information
Application/Usage:
  • Optical Network
  • Data Networking

Interfaces/Ports
Total Number of Ports:1
Connector Type:LC
Interfaces/Ports Details:1 x LC Duplex 10GBase-BX Network
Media & Performance
Media Type Supported:Optical Fiber
Fiber Mode Supported:Single-mode
Ethernet Technology:10 Gigabit Ethernet
Network Technology:10GBase-BX
Physical Characteristics
Form Factor:Hot-swappable
Height:0.5"
Width:0.5"
Depth:2.3"
Weight (Approximate):0.05 lb
Miscellaneous
Compatibility:MSA Compliant
Environmentally Friendly:Yes
Environmental Certification:
  • WEEE
  • RoHS
  • REACH

Country of Origin:China
Warranty
Limited Warranty:Lifetime
