General Information

---

Manufacturer:StarTech.com
Manufacturer Part Number:N6PATCH15WH
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Model:N6PATCH15WH
Product Name:15 ft White Snagless Cat6 UTP Patch Cable
Marketing Information:

The N6PATCH15WH Cat 6 Patch Cable (15 ft) meets or exceeds all Category 6 cable specifications to ensure reliable Gigabit network connections, and features a durable white PVC jacket that enables you to color code your network cable runs as needed.

To ensure long-lasting performance, this high quality Cat 6 patch cable features a snagless design that protects the RJ45 connector clips from damage and makes the cable less prone to snagging during installation. The cable also features molded PVC strain relief that prevents the RJ45 connector termination points from bending at sharp angles - reducing the risk of cable damage, which could decrease network performance.

Constructed of only top quality materials, this Cat 6 Patch Cord delivers reliable performance and is backed by our Lifetime Warranty.

100% Copper - a better value

StarTech.com Cat6 cables are manufactured using high-quality copper conductors. While many cable manufacturers offer a "cheaper" cable based on a copper-coated aluminum core, we make no compromises on quality to ensure you receive top value and performance for your network cable investment.

24 AWG Wire

This Cat6 cable is constructed with 24 gauge copper wire, to support a broad range of Ethernet applications such as Power over Ethernet (PoE). Because we use a high quality copper wire, our cables easily sustain the power required for Power over Ethernet applications, whereas the inferior quality offered by copper-coated aluminum cables may be subject to insufficient power delivery, heat buildup, equipment damage and potentially, fire.

50-micron Gold Connectors

This Cat 6 patch cable offers high quality connectors comprised of 50-micron gold, to deliver optimum conductivity while eliminating signal loss due to oxidation or corrosion.

Product Type:Network Cable

Technical Information

---

Cable Type:Category 6
Cable Characteristic:Patch Cable
Cable Length:15 ft
Connector Type on First End:RJ-45 Network - Male
Connector on First End Details:1 x RJ-45 Network - Male
Connector Type on Second End:RJ-45 Network - Male
Connector on Second End Details:1 x RJ-45 Network - Male
Connector Plating:Gold
Features:

• Molded
• Strain Relief
• Damage Resistant
• Corrosion Resistant
• Stranded
• Fray Resistant
• Rust Resistant
• Bend Resistant
• PoE

Conductor:Copper
Jacket Type:CMG
Device Supported:

• Network Device
• Workstation
• Wall Outlet
• Distribution Panel
• Hub
• Security Device
• VoIP Device

American Wire Gauge:24 AWG
Data Transfer Rate:10 Gbit/s
Boot Type:

• Snagless
• Molded

Physical Characteristics

---

Product Color:White
Jacket Material:Polyvinyl Chloride (PVC)
Weight (Approximate):0.46 lb

Miscellaneous

---

Certifications & Standards:

• ETL Verified
• UL Listed
• ANSI/TIA-568-B
• CMG Rated
• TIA/EIA-568-B.1-2001 T568B

Environmentally Friendly:Yes
Environmental Certification:

• RoHS
• WEEE
• REACH

Country of Origin:China

Warranty

---

Limited Warranty:Lifetime
