NIC ADAPTER NETWORK CARD
HARDWARE
Bus Type
PCI Express
Card Type
Standard Profile (LP bracket incl.)
Chipset ID
Intel XL710-BM1
Industry Standards
IEEE 802.3ba 40GBASE-SR4
IEEE 802.3ba 40GBASE-LR4
PCI Express Rev 3.0, using PCIe x8 (or higher) slot
Ports
1
PERFORMANCE
Auto MDIX
Yes
Compatible Networks
40 Gbps
Full Duplex Support
Yes
Jumbo Frame Support
9K max.
Maximum Data Transfer Rate
40Gbps
Supported Protocols
IEEE 802.3ad (Link Aggregation)
IEEE 802.3x (2005 Flow Control Support)
IEEE 802.1Q (VLAN tagging)
CONNECTOR(S)
Connector Type(s)
1 - PCI Express x8 Male
Internal Ports
1 - QSFP+ Female
SOFTWARE
OS Compatibility
Windows 7, 8, 8.1, 10
Windows Server 2008 R2, 2012, 2012 R2, 2016, 2019
(Windows Drivers are supported in 64-bit only)
Linux 2.6.24 to 4.11.x (64-bit Only)< LTS Versions only
INDICATORS
LED Indicators
1 - Link LED/Activity LED
ENVIRONMENTAL
Humidity
5 to 95% RH
Operating Temperature
0^oC to 57^oC (32^oF to 134.6^oF)
Storage Temperature
-20^oC to 85^oC (-4^oF to 185^oF)
PHYSICAL CHARACTERISTICS
Color
Black
WHATS IN THE BOX
Included in Package
1 - Network Card
1 - Low-Profile Bracket
1 - Quick-Start Guide
Item Dimension ( L inchxW inchxH inch)
9 x 5 x 2 Weight
1 lb Warranty Information
2 Year Warranty
