General Information

---

Manufacturer:StarTech.com
Manufacturer Part Number:NOTECONS01
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:KVM Console to USB 2.0 Portable Laptop Adapter
Marketing Information:

The NOTECONS01 KVM Console to USB 2.0 Portable Laptop Crash Cart Adapter turns your notebook or netbook into a portable server crashcart, eliminating the need to lug around a large, heavy and awkward video screen, keyboard, and mouse. This adapter delivers the VGA stream from any host computer to a laptop and emulates the laptop mouse and keyboard outputs for simple access and control of connected servers, PCs or other "headless" devices.

"StarTech.com's USB KVM may be your new best friend for trips to the datacenter... you can use this from the back of the rack. So if you are handling issues that require moving cables or network connections... this can be a major timesaver."
- everythingUSB.com

"The CRN Test Center recommends StarTech's Crash Cart Adapter for any company with a data center or with technicians servicing computers in the field"
- CRN

With portability for the mobile administrator or repair technician in mind, this USB-powered adapter features a small-footprint design that requires no additional accessories to connect to most servers, and requires no server-side software installation. Plus, the pocket-sized adapter draws its power from the server-side USB connections, allowing the laptop/netbook to last longer without consuming battery power.

Ensuring full control of the connected units, the Laptop KVM Server Console Adapter provides immediate access to the POST screen and BIOS, plus the ability to handle full configuration of the attached PC or machine; administrators can connect to a headless server/device without the need of an expensive LCD rackmount console or bulky monitor, keyboard and mouse solution.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

How it works:

Product Type:KVM Cable

Technical Information

---

Connector Type on First End:USB Type A - Female
Connector on First End Details:1 x USB Type A - Female
Connector Type on Second End:

• USB Type A - Male
• HD-15 - Male

Connector on Second End Details:

• 1 x USB Type A - Male
• 1 x 15-pin HD-15 - Male

Features:

• LED
• USB- Power Delivery (USB PD)

Device Supported:

• KVM Console
• Notebook
• Netbook
• Keyboard
• PC

Supported Resolution:1920 x 1200

Physical Characteristics

---

Product Color:Black
Weight (Approximate):0.37 lb

Miscellaneous

---

Package Contents:

• USB PS/2 KVM Console Adapter
• USB Cable
• USB to PS/2 Adapter

Additional Information:

OS Compatibility:

• Windows® XP, Vista, 7, 8, 8.1, 10
• Windows Server® 2008 R2, 2012, 2016, 2019
• Mac OS® 10.6 to 10.14
• Linux 2.6.x to 4.11.x (LTS Versions Only)

Environmentally Friendly:Yes
Environmental Certification:

• RoHS
• REACH
• WEEE

Country of Origin:Canada
TAA Compliant:Yes

Warranty

---

Limited Warranty:2 Year
