WITH EXTERNAL POWER ADAPTER
HARDWARE
Bus Type
USB 3.0
Chipset ID
Genesys Logic - GL3523
Fast-Charge Port(s)
Yes
Industry Standards
USB Battery Charging Specification Rev. 1.2
USB 3.2 Gen 1 - Backwards compatible with USB 3.0, 3.0, and 1.1
Interface
USB 3.0
Ports
10
USB-C Device Port(s)
No
USB-C Host Connection
No
PERFORMANCE
ESD Protection
+/-15kV (Air)
+/-8kV (Contact)
Maximum Data Transfer Rate
5 Gbps
MTBF
126,106 Hours
Surge Protection
350W on the DFP and UFP
Type and Rate
USB 3.0 - 5 Gbit/s
UASP Support
Yes
CONNECTOR(S)
Connector Type(s)
10 - USB 3.1 USB Type-A (9 pin, Gen 1, 5 Gbps) Female
1 - USB Type-B (9 pin) USB 3.0 Female
1 - Terminal Block (2 Wire)
SOFTWARE
OS Compatibility
OS Independent No additional drivers or software required
SPECIAL NOTES / REQUIREMENTS
Note
If connected to a USB 2.0 host port, performance may be limited
This product is intended for use with terminal block power only Standard AC adapter not available
System and Cable Requirements
Host computer with an available USB 3.0 port
INDICATORS
LED Indicators
1 - Power (Green)
POWER
Input Current
1.4A
Input Voltage
100 - 240 AC
Output Current
3.25A
Output Voltage
20V DC
Plug Type
Terminal Block (2 Wire)
Power Consumption (In Watts)
65W
Power Source
AC Adapter Included
ENVIRONMENTAL
Humidity
5%-95% RH (Non-condensing)
Operating Temperature
0^oC to 70^oC (32^oF to 158^oF)
Storage Temperature
-20^oC to 85^oC (-4^oF to 185^oF)
PHYSICAL CHARACTERISTICS
Color
Black
Form Factor
Industrial
WHATS IN THE BOX
Included in Package
1 - USB Hub
1 - USB 3.0 Host Cable
1 - Universal Power Adapter (NA/JP, ANZ, UK, EU)
2 - DIN Rail Brackets
4 - Mounting Screws
1 - Quick-Start Guide
Item Dimension (L"x W"x H")
10 x 7 x 3
Weight
2.00 LB
Warranty Information
2 Year Warranty
