The ZyXEL GS1900 Series of 8/10/16/24/48-port GbE Smart Managed Switch with Gigabit speed and essential managing functions bring your business network more flexibility and connectivity. The 1900 Series consists of nine (9) models?the GS1900-8, GS1900-8HP, GS1900-10HP, GS1900- 16, GS1900-24E, GS1900-24, GS1900-24HP, GS1900-48 and GS1900-48HP. Providing GbE switches with power-saving functions, fanless design and full IPv6 support ensure your network to be ready for future expansions. In addition, the PoE models GS1900-8HP/10HP/24HP/48HP Gigabit switch complies with the IEEE 802.3at Power over Ethernet (PoE) Plus standard. The complete GS1900 Series has been designed with useful features and advanced performances that empower your networks with speed and security as well as silent operation in your office environments.
Standard Compliance IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Ethernet IEEE 802.3ab (1000BASE-T) Ethernet IEEE 802.3x flow control IEEE 802.3az EEE support IEEE 802.1p CoS support IEEE 802.3af PoE (GS1900-8HP/10HP/24HP/48HP) IEEE 802.3at PoE plus (GS1900-8HP/10HP/24HP/48HP) IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) Full-duplex and half duplex operation with IEEE 802.3x flow control and backpressure Store and forward Auto MDI/MID-XResilience and Availability IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) IEEE 802.3ad LACP Dual configuration files Dual imagesTraffic Management and QoS Port-based VLAN IEEE 802.1Q VLAN tagging IEEE 802.3ad LACP Guest VLAN Voice VLAN Storm control IEEE 802.1p priority queues per port IEEE 802.1p Queuing method (scheduler) Input priority mapping Rate limiting per port (ingress/egress) IEEE 802.3x flow controlClass of Service (CoS) IEEE 802.1p class of service (SPQ, WRR) Port-based CoS IP TOS precedenceSecurity IEEE 802.1x Port security Layer 2 MAC filtering BPDU guard Static MAC forwarding RADIUS TACACS+ SSL Management VLAN CPU defense engine DoS preventionLayer 2 Multicast IGMP snooping (v1, v2, v3)IPv6 IPv6 over Ethernet (RFC 2464) Dual-stack (RFC 4213) ICMPv6 (RFC 4884) Neighbor discovery (RFC 4861) Auto configuration Static IPv6 address and prefix length Static IPv6 default gateway IPv6 duplicate address detectionDiscovery IEEE 802.1 AB LLDP LLDP-MEDNetwork Management SNMP v1, v2, v3 RMON (1, 2, 3, 9) ICMP echo/echo reply SyslogMIB RFC 1213 MIB II RFC 2819 RMON (group 1, 2, 3, 9) RFC 1215 generic traps RFC 1493 bridge Private MIBCertifications EMC CE, FCC, C-Tick, Class A (GS1900-24/24HP/48/48HP) CE, FCC, C-Tick, Class B (GS1900-8/8HP/10HP/16/24E) BSMI CNS13438 Safety LVD EN60950-1 BSMI CNS14336-1 CB IEC60950-1 (GS1900-8HP/10HP/16/24E/24) RoHS compliantZyXEL One Network ZON Utility Discovery of ZyXEL switches, APs and gateways Centralized and batch configurations IP configuration IP renew New Device factory reset Device reboot Device locating Web GUI access Firmware upgrade Password configuration One-click quick association with ZyXEL AP Configurator (ZAC)10/100/1000 BASE-T, fixed 24 SFP 100/1000 Mbps 2Switching capacity (Gbps) 52Switch forwarding rate (Mpps) 39Packet buffer (byte) 525 KMAC address 8 KJumbo frame (byte) 9 KInput voltage of AC 100 - 240 V AC, 50/60 HzMax. power consumption (watt) 16Item Dimensions (WxDxH) (mm/in.) 440 x 131 x 44/17.32 x 5.16 x 1.73Item Weight (kg/lb.) 2.09/4.60Packing Dimensions (WxDxH) (mm/in.) 561 x 217 x 82/21.97 x 8.54 x 3.23Packing Weight (kg/lb.) 2.85/6.28Included accessories Power cord, Rack mounting kitOperating temperature 0°C to 50°C/32°F to 122°F Storage temperature -40°C to 70°C/-40°F to 158°F Operating humidity 10% to 95% (non-condensing)
