GS1200-5HP - Fanless 5 Port GbE POE+ L2 Web Managed Switch (60W)
Models
GS1200-5HP : 5-port GbE Web Managed PoE Switch Chipset
Main chip : Broadcom BCM53125
CPU : IC Plus IP210W Port Density
Total port count : 5
1000BASE-T : 1
PoE : 4 Performance
Switching capacity : 10 Gbps
Packet buffer : 128 KB
MAC address : 4K
Jumbo frame : 9 KB LED
Power : Yes
Per port : Yes
PoE power status : Yes (Max) Power
Input voltage : 55 V/1.3 A
Power supply : External
Maximum power consumption (watt) : 72
PoE power budget (watt) : 60 Environmental Specifications
Operating temperature : 0C to 40C/32F to 104F
Operating humidity : 10% to 90% (non-condensing)
Storage temperature : -40C to 70C/-40F to 158F
Storage temperature : 10% to 90% (non-condensing) Standard Compliance
IEEE 802.3u 100BASE-TX Ethernet : Yes
IEEE 802.3ab 1000BASE-T Ethernet : Yes
IEEE 802.3az EEE support : Yes
IEEE 802.3x flow control : Yes
IEEE 802.3z 1000BASE-X : Yes
IEEE 802.1p CoS : Yes
IEEE 802.3af PoE : Yes
IEEE 802.3at PoE Plus : Yes (30W per port)
Auto MDI/MDI-X : Yes
IEEE802.1Q VLAN tagging : Yes Features
Web-based management : Yes
System password : Yes
Port-based VLAN : Yes
VLAN ( Supported) : 5
Port-based QoS : Yes
802.1p CoS : Yes
Broadcast storm control : Yes
Loop detection : -
Weighted Round Robin (WRR) priority QoS : Yes
IGMP snooping v1/v2/and v3 compatible : Yes
Supported multicast groups : 20
Firmware update : Yes Certification
EMC : CE, FCC, C-Tick, Class A : Yes
Safety : LVD EN60950-1 : Yes
RoHS compliant : Yes Item Dimension (L inchxW inchxH inch)
8 x 4 x 2

Weight
1.00 lb

Warranty Information
2 Years
