PCAP ANTI-G ZERO-BEZ NO STAND BLACK

Part Number(s)
Black Without Stand (Worldwide) - E683595 Enclosure Color
Black Touch Technology and Capacity
PCAP (Projected Capacitive) - 10 Touch Diagonal Size
13.3" diagonal, Active matrix TFT LCD Aspect Ratio
16:9 Active Area (mm)
11.57" x 6.51" / 293.76 mm x 165.24 mm Resolution
1920 x 1080 Other Supported Resolutions
640 x 480 60Hz
800 x 600 60Hz
1024 x 768 60Hz
1280 x 720 60Hz
1280 x 800 60Hz, 60Hz RB
1280 x 960 60Hz
1280 x 1024 60Hz
1360 x 768 60Hz
1366 x 768 60Hz, 60Hz RB
1440 x 900 60Hz, 60Hz RB
1680 x 1050 60Hz, 60Hz RB
1920 x 1080 60Hz Viewing Angle
Horizontal: +/-85o or 170o total / Vertical: +/-85o or 170o total Number of Colors
16.7 million Brightness (typical)
Panel: 300 nits TouchPro PCAP: 270 nits Response Time-total (typical)
25 msec Contrast Ratio
800:1 Touch Interfaces
USB Surface Treatment
Anti-glare On Screen Display
Accessible through switches along the bottom:

Controls: Menu, Up, Down, Select, Power

Settings: Brightness, Contrast, Clock, Phase, H-Position, V-Position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Recall Defaults, Video Priority, Information, Touch on Sleep Mode, Energy Saver, Panel Saver, Mute, Volume, Audio Source

Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese,

Lockouts: OSD, Power I/O Ports
1 x Full-function USB-C (Requires PD Power Delivery, USB 3.0 and Display Port)
1 x Audio jack (Line-in)
1 x VGA
1 x HDMI
1 x 12V D/C input
4x Micro-USB ports (Top, Bottom, Left, Right) for Elo Edge Connect peripherals Speakers
2 x 1W Video
HDMI V1.3 Type A receptacle for HDMI input
Analog VGA
USB Type-C Input Video Frequency
Horizontal: 30 75K KHz
Vertical: 60Hz
