HARDWARE
4K Support
Yes
Bus Type
USB-C
USB 3.0
Chipset ID
DisplayLink - DL6950
Genesys Logic - GL3523
Fresco Logic - FL7102
Fresco Logic - FL7201
VIA Labs - VL160
RealTek - RTL8153
Texas Instruments - TS3A225E
Displays Supported
2
Fast-Charge Port(s)
Yes
Industry Standards
USB Power Delivery Specification Rev. 3.0
USB Battery Charging Specification Rev. 1.2
DisplayPort 1.2
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Interface
USB 3.0
K-Lock Slot
Kensington Standard Slot (K-Slot) PERFORMANCE
Compatible Networks
10/100/1000 Mbps
Full Duplex Support
Yes
Maximum Data Transfer Rate
5 Gbps (USB 3.0)
2 Gbps (Ethernet Full-Duplex)
Maximum Digital Resolutions
2x HDMI - 4096 x 2160p at 60Hz
2x DisplayPort - 4096 x 2160p at 60Hz
1x HDMI + 1x DisplayPort - 4096 x 2160p at 60Hz
1x 5K DisplayPort using 2 DP video ports - 5120 x 2880 at 60Hz
Lower resolutions are also supported. For example, if the max is 4096 x 2160p (4K), it also supports 3840 x 2160p (4K), 2560 x 1600p and 2560 x 1440p.
PXE
Yes
Type and Rate
USB 3.0 - 5 Gbit/s
UASP Support
Yes CONNECTOR(S)
Connector Type(s)
2 - DisplayPort (20 pin) Female
2 - HDMI (19 pin) Female
1 - USB Type-C (Fast-Charge, 24 pin) USB 3.0 Female
1 - USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
2 - USB Type-A (9 pin) USB 3.0 Female
1 - Ethernet Gigabit Female
1 - 3.5 mm Mini-Jack (4 Position) Female SOFTWARE
OS Compatibility
Windows 7, 8, 8.1, 10
macOS 10.11 - 10.12, 10.14
Chrome OS v55+ SPECIAL NOTES / REQUIREMENTS
Note
Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host USB-C port supports USB Power Delivery and DP alt mode.
4K resolution is supported on all 4 video ports. A 4K-capable DisplayPort or HDMI display is required to achieve 4Kx2K resolutions
If connected to a USB 2.0 host port, or if using a USB 2.0 host connection cable, performance may be limited (USB 3.0 host cable included)
USB 3.0 is also known as USB 3.1 Gen 1 this connectivity standard offers speeds up to 5Gbps
5K resolution is supported by connecting the two DisplayPort video ports to a single 5K display. A 5K-capable display is required to achieve 5K (5120 x 2880 60Hz) resolutions
The dock connects to the USB Type-C port or the USB Type-A port on your laptop.
System and Cable Requirements
USB-C enabled computer with an available USB Type-C port, or a USB-3.0 enabled computer with an available USB Type-A port POWER
Center Tip Polarity
Positive
Input Current
2.5 A
Input Voltage
100 - 240 AC
Output Current
6.75 A
Output Voltage
20V DC
Plug Type
N
Power Consumption (In Watts)
135 W
Power Delivery
60W
Power Source
AC Adapter Included ENVIRONMENTAL
Humidity
0-95% RH
Operating Temperature
0^oC to 50^oC (32^oF to 122^oF)
Storage Temperature
-20^oC to 70^oC (-4^oF to 158^oF) PHYSICAL CHARACTERISTICS
Color
Black and Space Gray
Enclosure Type
Plastic WHATS IN THE BOX
Included in Package
1 - Docking Station
1 - USB-C Cable (with Attached USB-C to USB-A Adapter)
1 - Universal Power Adapter (NA/JP, ANZ)
1 - Quick-Start Guide Item Dimension (L"xW"xH")
11 x 7 x 4

Weight
3 lbs

Warranty Information
3 Year Warranty
