Form Factor
Mid-tower chassis - supports for maximum motherboard sizes: 12 inch x 13 inch E-ATX and ATX
Processor Support
Dual and Single Intel and AMD processors
Available Color
Black
Expansion Slots
7 full-height and full-length expansion slot(s)
Drive Bays
4 x 3.5 inch hot-swap SAS/SATA drive bay with SGPIO
Backplane
4x3.5 inch SAS2/SATA3 backplane w/SES-II
Peripheral Drives
2 x standard 5.25 inch drive bay
1 x 3.5 inch internal fixed drive bay
Front Panel
Buttons
Power On/Off button
System Reset Button
LEDs
1 Network Activity LEDs
HDD activity LED
Power LED
System Overheat LED
Ports
2x USB 2.0 Port(s)
Systems Cooling
Fans
1 x 12cm rear exhaust fan(s)
1 x 9cm hot-swap cooling fan(s)
Operating Environment (System)
Operating Temperature Range
5oC - 35oC (41oF - 95oF)
Non-Operating Temperature Range
-40oC - 70oC (-40oF - 158oF)
Operating Relative Humidity Range
8% - 90% (non-condensing)
Non-Operating Relative Humidity Range
5% - 95% (non-condensing)
Power Supply
PS2 668W Multi-output power supply 80PLUS Platinum
Power Efficiency
92%
Total Output Power and Input
668W with Input 100 - 240Vac
AC Input Frequency
50-60Hz
Output Type
24pin ATX
-12V
Max: 0.1A / Min: 0A
+12V
Max: 54A / Min: 0.2A (100Vac - 240Vac)
+5V
Max: 11.8A / Min: 0.1A
