General Information Articulating/full-motion desktop mount for three monitors from 13" to 27" and up to 22 lbs (10 kgs) each Gets monitors out of the way and frees up valuable desk workspace Supports tilt angles of +/-45o, 180o swivel (center monitor limited to +/- 15o), 360o rotation for easy adjustment of viewing angle Center VESA plate allows vertical height adjustment up to 1" to further level with both side display units Left and right triple-section mounting arm that extends up to 27" and allows height adjustment up to 17.5" for proper monitor positioning Supports portrait or landscape monitor orientations Installs quickly and easily on to any desk or table Heavy duty C-clamp is compatible with table and desk surfaces from " to 4" in thickness or can be installed via grommet/through-hole up to 2 " wide Integrated cable management system keeps cables neat, organized and out of the way Compatible with VESA mounting 75x75mm and 100x100mm patterns Includes installation guide and mounting hardware kit Product InformationDevice Supported: MonitorNumber of Displays Supported: 6Maximum Load Capacity: 66 lbMinimum Screen Size Supported: 13"Maximum Screen Size Supported: 27"Physical CharacteristicsColor: BlackVESA Mount Standard: 75 x 75VESA Mount Standard: 100 x 100Material: SteelHeight: 24.5"Width: 53.2"Depth: 7.9"Weight (Approximate): 17.70 lbMiscellaneousPackage Contents: Articulating Triple Monitor Desk Mount - 13" to 27" Hardware Kit Installation Instructions Assembly Required: YesEnvironmentally Friendly: YesEnvironmental Certification: RoHSCountry of Origin: ChinaWarrantyLimited Warranty: 5 Year
Supports monitors up to 22 lbs (10 kgs) Screen size:
13inch to 27inch Tilt angle:
+/-45 degrees Swivel:
180 degrees (left and right arm, center monitor limited to +/- 15 degrees) Rotation:
360 degrees Height adjustment:
Up to 17.5 inch Dual articulating mounting arms extend up to 27 inch Distance between the VESA mounts (center to center):
26 inch (max) Compatible with VESA mounting 75x75mm and 100x100mm patterns Material:
Steel Mounting options:
C-Clamp: Compatible with table or desk surfaces from 1/2 inch to 4 inch thick
Grommet: Compatible with surface hole from 3/8 inch to 2 inch wide and up to 2 1/2 inch thick Tube Support:
Length: 17.5 inch
Diameter: 1.9 inch Color: Black Certifications/Standards:
RoHS Country of origin:
China Item Dimension (L inchxW inchxH inch)
5 x 32 x 12

Weight
18.20 lb

Warranty Information
5 Years
