Specifications
Compatible with HDMI 2.0 HDCP version: HDCP2.2, HDCP1.4 (Auto detection depends on TV version) Max resolution: 4K at 60Hz YUV4:4:4 Control: Switch button and Remote control Audio: Analog audio 2.0, SPDIF 5.1, audio extraction Audio format: Dolby True HD and DTS-HD master audio (HDMI out) Transmission distance: 1080P 20m, 4K at 30Hz 10m, 4K at 60Hz (including HDR) up to 3m Minimum power consumption (under 480p60hz): 256mA Maximum power consumption (4K/60hz): 383mA Color: Black Housing: Metal Connectors:
4x 19-pin, HDMI, Female, Input 1x 19-pin, HDMI, Female, Output 1x Switch button 1x ARC button 1x EDID button 1x Audio In button 10x Source and Audio LED 1x IR Receiver 1x Power LED
