Compatibility:
HDMI 2.0, HDCP 2.2, 3D, Deep color
Video bandwidth:
Single-link 594MHz, Up to 18Gbps
Resolution:
Up to 3840x2160 at 60Hz YUV 4:4:4 8-bit and 3840x2160 at 60Hz YUV 4:2:0 10-bit HDR
Audio:
Surround sound (up to 7.1ch) or stereo digital audio
HDMI: PCM, Dolby Digital, DTS-HD and Dolby True-HD audio
3.5mm Jack: PCM 2-CH stereo Audio
USB data transfer rate:
USB 1.1: up to 12Mbps
USB 3.0: up to 5Gbps
Product:
Color: Black
Housing material: Metal
Connector:
4x 19-pin HDMI, Female, PC Input
4x 9-pin USB 3.0 Type-B, Female
4x 3.5mm jack for Mic and Stereo audio, Female, PC Input
1x 19-pin, HDMI, Female, Output
1x 3.5mm jack for Mic and Stereo audio, Female, Output
1x 5-pin Micro USB, FW update, Female
4x 9-pin USB 3.0 Type-A, Female
2x 4-pin USB 1.1 Type-A, Female for Keyboard and Mouse
1x 2-pin DIP Switch, Control FW
1x Power Jack
Power adapter:
Input: 100-240VAC, 50/60 Hz
Output: DC 12V/2A
UL listed: E163743 8F35/Level: VI
Environmental conditions:
Operating temperature: 32 to 104 degrees F
Storage temperature: -4 to 140 degrees F
Relative humidity: <85% RH (non-condensing)
TAA compliant
Certifications/Standards:
FCC, CE, RoHS
Item Dimension (L"xW"xH")
12 x 3 x 5
Weight
2.09 LB
Warranty Information
3 years
