Compliant with HDMI 1.4 and HDCP 1.4 Supported resolution:
480i / 480p / 576i / 576p / 720p / 1080i / 1080p / 4Kx2K at 30Hz Supported video color format:
xv-YCC / Deep color 36-bit Video bandwidth:
10.2Gbps Audio formats:
DTS-HD / Dolby True-HD / LPCM / AC3 / DTS / DSD Input TMDS signal:
5-1.0V (peak-to-peak) Input DDC signal:
5V (peak-to-peak, TTL) HDMI cable length:
up to 15 meters (Input 5m / Output 10m) Power consumption:
15 watts Power and link LED indicator Product:
Color: Black
Housing: Metal Connectors:
1x 19-pin, HDMI, Type A, Female, Input
16x 19-pin, HDMI, Type A, Female, Output
1x Power Switch, On/Off Power adapter:
Input: 100-240VAC, 50/60 Hz
Output: 5V/4A
UL Listed: E476609 / Level: VI Environmental conditions:
Operating temperature: 32 to 104 degrees F
Storage temperature: 14 to 140 degrees F
Relative humidity: 5 to 90% RH (non-condensing) Certifications/Standards:
FCC, CE, RoHS Item Dimension (L"xW"xH")
14 x 2 x 6

Weight
3.31 lbs

Warranty Information
2 years
