The CE750A is a USB-based KVM Extender with automatic signal compensation and RS-232 serial functionality that allows access to a computer system from a remote USB console (USB keyboard, monitor, and USB mouse). Because it allows access to a computer system from a remote console, the CE750A is perfect for use in any type of installation where you need to place the console where it is conveniently accessible, but you want the system equipment to reside in a safe location ? for example away from the dust and dirt of the factory floor or the harsh environment of a construction site. The CE750A improves on previous designs by the addition of an RS-232 port, on both the Local and Remote Units, that allows you to connect to a serial terminal for configuration (Local Unit) or serial devices such as touchscreens and barcode scanners (Remote Unit).
Local and Remote units connect at distances up to 200 meters using Cat 5e cable Dual console operation ? control your system from both the local and remote USB keyboard, monitor, and mouse consolesBuilt-in ASIC for greater reliability and compatibility USB keyboard and USB mouse portsRS-232 serial ports ? allows you to connect to a serial terminal for configuration (Local Unit) or serial devices such as touchscreens and barcode scanners (Remote Unit) Supports stereo speakers and stereo microphoneUSB overcurrent detection and prevention Pushbutton operating mode selection (Local Unit only) ? select between Local and Auto operating modesBuilt-in 8KV/15KV ESD protection (contact voltage 8KV, air voltage 15KV) and 2KV surge protection Adjustable gain control ? automatically and manually adjusts signal strength to compensate for distanceHigh resolution video ? up to 1920x1200@60Hz at 30m,1600x1200@60Hz at 150m, 1280x1024@60Hz at 200m Supports VGA, SVGA, SXGA (1280 x 1024), UXGA (1600 x 1200), and multisync monitors; local monitor supports DDC, DDC2, DDC2BHot pluggable Rack mountableEasy to install ? no software required, simply connect cables to the devices Supports wide screen formatsProduct Type KVM Console/ExtenderTechnical Information Connectivity Technology Wired Number of Computers Supported 1 Number of Local Users Supported 1 Number of Remote Users Supported 1 Maximum Operating Distance 200mVideo Graphic Mode WUXGA Maximum Video Resolution 1920 x 1200Interfaces/Ports Network (RJ-45) Yes USB Yes VGA Yes Number of VGA Ports 2 Number of Network (RJ-45) Ports 2 Number of USB Ports 4Power Description Input Voltage 5.3V DCPhysical Characteristics Transmitter Height 0.98" Transmitter Width 3.4" Transmitter Depth 7.95" Receiver Height 0.98" Receiver Width 3.35" Receiver Depth 7.95" Transmitter Weight (Approximate) 1.04lb Receiver Weight (Approximate) 1.04lbPackage Contents 1 x CE750AL USB KVM Extender (Local Unit) 1 x CE750AR USB KVM Extender (Remote Unit) 1 x Custom KVM Cable Set 2 x Power Adapters 1 x Mounting Kit 1 x User InstructionsEnvironmentally Friendly YesEnvironmental Certification RoHS WEEE
