General Information

---

Manufacturer:StarTech.com
Manufacturer Part Number:ST4000SPEXI
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:4-Port Gigabit Ethernet Network Card - PCI Express, Intel I350 NIC
Marketing Information:Here's a dependable and cost-effective way to add four high-performance Gigabit Ethernet ports to your server or desktop computer, through one PCI Express slot.

Reliable network connectivity with high performance

This Gigabit Ethernet network card features the Intel® I350-AM4 chipset, designed to deliver the power, performance and enhanced capabilities you need for reliable network connections to your server or computer. The Intel chip provides a number of advanced driver options includingIEEE 802.3ad link aggregation / teaming support, which enablesyou to add additional bandwidth to your system.

Compliant with IEEE 802.3/u/ab standards, the network card provides full support for high-performance, four-channel networking and maximum throughput up to 1000Mbps in each direction (2000 Mbps total) - up to ten times faster than 10/100 Ethernet.

Cost-effective access to multiple networks

The quad-port Gigabit network card makes it easy to access multiple networks. It offers a cost-effective solution for IT professionals in government, educational, corporate, health care, or business environments where access to multiple networks from numerous workstations is needed. The server adapter card gives youfour redundant, independent Gigabit Ethernet portsand it supports advanced features such as Jumbo Frames and VLAN tagging.

Enhanced versatility and efficiency

Compatible with a broad range of operating systems, this versatile PCIe Gigabit NIC is suitable for many business and enterprise applications - including virtualized environments with multiple operating systems, requiring multiple shared or dedicated NICs.The 4-port Gigabit network card is equipped with Intel® Virtualization Technologyfor Connectivity (Intel® VT-c) which reduces system latency and improves networking throughput. Four dedicated ports allow you to maximize your virtualized server's networking efficiency and create a more agile data center.

With adual-profile design, the PCI Express network cardinstalls easily into a wide range of computer/server chassis, regardless of form factor. The card is equipped with a full-sized bracket, and includes a low-profile/half-height installation bracket that you can use as needed.

The ST4000SPEXI is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Packaged Quantity:1
Product Type:Gigabit Ethernet Card

Technical Information

---

Chipset Manufacturer:Intel
Chipset Model:I350-AM4

Interfaces/Ports

---

Host Interface:PCI Express x4
Total Number of Ports:4
Number of Network (RJ-45) Ports:4

Media & Performance

---

Media Type Supported:Twisted Pair

Network & Communication

---

Network Technology:10/100/1000Base-T

Physical Characteristics

---

Product Color:Black
Form Factor:Plug-in Card
Height:4.7"
Width:0.7"
Length:5.2"
Weight (Approximate):3.20 oz

Miscellaneous

---

Package Contents:

• 4-Port Gigabit Ethernet Network Card - PCI Express, Intel I350 NIC
• 1 x Low Profile Bracket
• 1 x Instruction Manual

Device Supported:Computer
System Requirements:

• Windows® 7, 8, 8.1, 10
• Windows Server® 2008 R2, 2012, 2012 R2, 2016, 2019
• Linux 2.4.x to 4.11.x LTS versions only

Environmentally Friendly:Yes
Environmental Certification:

• RoHS
• WEEE
• REACH

Country of Origin:China

Warranty

---

Limited Warranty:2 Year
