Apc Back-ups System (cs 500) APCBK500BLK

MFG No: BK500BLK
SKU No: P1P8KUKIHE
UPC: 731304021360
MFG. Name: APC - Schneider Electric
Available: 367
Condition: New

$160.32


Includes: CD with software Cord management straps USB cable User Manual.Output:Output Power Capacity: 300 Watts / 500 VA.Max Configurable Power: 300 Watts / 500 VA.Nominal Output Voltage: 120V.Output Connections: (3) NEMA 5-15R (Battery Backup) (3) NEMA 5-15R (Surge Protection).Input:Nominal Input Voltage: 120V.Input Frequency: 50/60 Hz +/- 3 Hz (auto sensing).Input Connections: NEMA 5-15P.Cord Length: 6 feet (1.83 meters).Input voltage range for main operations: 98 - 140V.Batteries and Runtime:Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: Leakproof.Typical recharge time: 8 hour(s).Replacement Battery: RBC2.RBC Quantity: 1.Communications and Management:Interface Port(s): DB-9 RS-232 USB.Control panel: LED status display with On Line: On Battery: Replace Battery and Overload indicators.Audible Alarm: Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm.Surge Protection and Filtering:Surge energy rating: 480 Joules.Filtering: Full time multi-pole noise filtering: 5% IEEE surge let-through: zero clamping response time: meets UL 1449.Data Line Protection: Analog phone line for phone/fax/modem/DSL (RJ-11 connector).Maximum Height: 6.50 inches (165 mm).Maximum Width: 3.60 inches (91 mm).Maximum Depth: 11.20 inches (284 mm).Color: Black.Units per Pallet: 80.00.Environmental:Operating Environment: 32 - 104 °F (0 - 40 °C).Operating Relative Humidity: 0 - 95%.Operating Elevation: 0-10000 feet (0-3000 meters).Storage Temperature: 5 - 113 °F (-15 - 45 °C).Storage Relative Humidity: 0 - 95%.Storage Elevation: 0-50000 feet (0-15000 meters).Audible noise at 1 meter from surface of unit: 45.00 dBA.Online Thermal Dissipation: 24.00 BTU/hr.Conformance:Regulatory Approvals: FCC Part 15 Class B Industry Canada UL 1778 cUL Listed.Standard : 3 years repair or replace.Environmental Compliance: RoHS REACH: Contains No SVHCs.- SKU: DHBK500BLK


6 outlets--3 UPS/surge, 3 surge only
1,020 Joules
2 block-spaced outlets
RJ11 modem/fax/DSL protection (2 wire single line)
Audible alarm
LED status display with on line/on battery/replace battery & overload indicators
User-replaceable batteries
USB compatible
Beige
6ft cord
Includes PowerChute(R) software
3-year warranty
Output power capacity: 500VA/300W
Typical run time: 15 min at half load, 3 min at full load
Lifetime $25,000 equipment protection policy
