General Information

---

Manufacturer:Schneider Electric SA
Manufacturer Part Number:AP8866
Manufacturer Website Address:http://www.schneider-electric.com
Brand Name:APC by Schneider Electric
Product Line:Metered Rack
Product Name:Rack PDU 2G, Metered, ZeroU, 17.2kW, 208V, (6) C13 & (12) C19
Marketing Information:

APC Metered Rack Power Distribution Units (PDUs) provide active metering to enable energy optimization and circuit protection. User-defined alarm thresholds mitigate risk with real-time local and remote alerts to warn of potential circuit overloads. Metered Rack PDUs provide power utilization data to allow Data Center Managers to make informed decisions on load balancing and right sizing IT environments to lower total cost of ownership. Metered Rack PDUs include real power monitoring, a temperature/humidity sensor port, locking IEC receptacles, and ultra low profile circuit breakers. Users can access and configure Metered Rack PDUs through secure Web, SNMP, or Telnet Interfaces which are complimented by APC Centralized Management platforms using InfraStruxure Central, Operations, Capacity, and Energy Efficiency.

Product Type:PDU

Technical Information

---

PDU Type:Metered
Receptacle Type:

• IEC 60320 C13
• IEC 60320 C19

Receptacle Detail:

• 6 x IEC 60320 C13
• 12 x IEC 60320 C19

Protection Type:Overload Protection

Power Description

---

Input Voltage:230 V AC
Output Voltage:208 V AC
Power Rating (VA):17.30 kVA

Management

---

Management:

Protocols:

• SNMP
• Telnet
• Web

Physical Characteristics

---

Product Color:Black
Mount Type:Rack-mountable
Number of Cord/Cable:1
Height:72"
Width:2.2"
Depth:2"
Weight (Approximate):20.94 lb

Miscellaneous

---

Package Contents:

Rack PDU 2G, Metered, ZeroU, 17.2kW, 208V, (6) C13 & (12) C19

Installation guide

Rack mounting brackets

Safety guide

Serial configuration cable

Additional Information:

Input Connections: IEC 309 60A 3P+PE

Certifications & Standards:

• cUL
• EN 55022 Class A
• EN 55024
• EN 61000-3-2
• EN 61000-3-3
• FCC Part 15 Class A
• ICES-003
• UL
• VCCI Class A

Environmentally Friendly:Yes
Environmental Certification:

• REACH
• RoHS

Warranty

---

Limited Warranty:2 Year
