ASUS Hyper M.2 X16 PCIe 3.0 X4 Expansion Card V2 Supports 4 NVMe M.2 (2242/2260/2280/22110) Upto 128 Gbps for Intel VROC and AMD Ryzen Threadripper NVMe Raid. Intel vroc ready and nvme raid support on amd ryzen threadripper. New two phase power solution with upto 14w output, Supports four additional nvme m.2 drives using intel vroc for transfer speeds upto 128gbps, Pci express 3.0 x16 interface, compatible with pci express x8 and x16 slots, Stylish heatsink and integrated blower style fan prevent M.2 throttling. Hyper M.2 x 16 card V2 is compatible with Intel Virtual RAID on CPU (VROC) and the AMD Ryzen Threadripper platform for NVMe RAID support. Unused CPU PCle lanes can be assigned to storage, allowing you to create a bootable RAID array with multiple M.2 SSDs. New two-phase power solution with up to 14 Watt output supports the latest NVMe drives. Large heatsink reduces M.2 SSD temperatures for unthrottled transfer speeds and enhanced reliability. Support for up to four PCIe 3.0 M.2 drives with transfer bandwidth up to 128Gbps. Intel VROC technology and AMD Ryzen Threadripper support enables creation of bootable NVMe RAID arrays using CPU PCIe lanes. The ASUS Hyper M.2 x16 V2 card provides four M.2 slots to let you expand your system with high-performance SSD storage. Designed for the latest generation of NVMe drives, the card features an upgraded power supply that provides up to 14W of power per drive, as well as a large heatsink and active fan to ensure drives stay cool for optimum performance. Hyper M.2 x16 is designed specifically for Intel Virtual RAID on CPU (VROC) and the AMD Ryzen Threadripper platform for NVMe RAID support and features four M.2 slots, providing up to 128 Gbps of bandwidth per card.
RAID on CPU
Hyper M.2 x 16 card V2 is compatible with Intel Virtual RAID on CPU (VROC) and the AMD Ryzen Threadripper platform for NVMe RAID support. Unused CPU PCle lanes can be assigned to storage, allowing you to create a bootable RAID array with multiple M.2 SSDs.
Design for unthrottled transfer speed
The ASUS Hyper M.2 x16 V2 card provides four M.2 slots to let you expand your system with high-performance SSD storage. Designed for the latest generation of NVMe drives, the card features an upgraded power supply that provides up to 14W of power per drive, as well as a large heatsink and active fan to ensure drives stay cool for optimum performance.
One card, 4X the bandwidth
Hyper M.2 x16 is designed specifically for Intel Virtual RAID on CPU (VROC) and the AMD Ryzen Threadripper platform for NVMe RAID support and features four M.2 slots, providing up to 128 Gbps of bandwidth per card.

Interface
PCI Express 3.0 x16 interface, compatible with PCI Express x8 and x16 slots, support data transfer rates up to 128 Gbps.
External Connectors
4 x M.2 Socket 3 with M Key design, type 2242/2260/2280/22110 storage devices support(Support PCIE SSD only)
LED and Button
1 x M.2 FAN Power Switch
4 x M.2 access LEDs
Features
RAID function Support:
Intel VROC ready for X299 Z370 Series Motherboard models. (It supports Intel SSDs only.)
AMD X399/X470/B450/X370/B350 Series Motherboard models
Item Dimension (L"xW"xH")
10 x 9 x 3

Weight
2 lbs

Warranty Information
1 Year
