The Intel® RealSense™ Depth Camera D400-Series uses stereo vision to calculate depth. The D415 is a USB-powered depth camera and consists of a pair of depth sensors, RGB sensor, and infrared projector. It is ideal for makers and developers to add depth perception capability to their prototype development. The depth camera includes: A powerful vision processor that uses 28 nanometer (nm) process technology and supports up to 5 MIPI Camera Serial Interface 2 lanes to compute real-time depth images and accelerate output New and advanced stereo depth algorithm for accurate depth perception and long range A set of image sensors that enable capturing of disparity between images up to 1280 x 720 resolution Support for the new cross-platform and open-source Intel® RealSense™ SDK 2.0 Dedicated color image signal processor for image adjustments and scaling color data Active infrared projector to...
Use Environment
Indoor/Outdoor Depth Technology
Active IR stereo Main Intel RealSense^TM component
- Intel RealSense^TM Vision Processor D4
- Intel RealSense^TM module D410
Depth Field of View (FOV) (Horizontal x Vertical x Diagonal)
65^o+/-2^o x 40^o+/-1^o x 72^o+/-2^o Depth Stream Output Resolution
Up to 1280 x 720 Depth Stream Output Frame Rate
Up to 90 fps Minimum Depth Distance (Min-Z)
0.3 m Sensor Shutter Type
Rolling Shutter Maximum Range
Approx. 10 meters, Varies depending on calibration, scene, and lighting condition RGB Sensor Resolution and Frame Rate
1920 x 1080 at 30 fps RGB Sensor FOV (Horizontal x Vertical x Diagonal)
69.4^o x 42.5^o x 77^o (+/- 3^o) Connectors
USB-C 3.1 Gen 1 Mounting Mechanism
- One 1/4-20 UNC thread mounting point
- Two M3 thread mounting points
Item Dimension (L"x W"x H")
11 x 6 x 5
Weight
3.00 LB
Warranty Information
1-years limited
