This robust DC power supply is designed for 12-volt communication and navigation systems on commercial vessels, ensuring reliability in critical environments. Its proven linear circuit design delivers a pure noise-free output and longevity.
Specifications:
Nominal Input Voltage: 115/230 VAC
Max Input Current @115: 7.5A
Max Input Current @230: 3.5A
Output Amperage (Intermittent/Continuous): 35A
Weight: 32 lbs. / 14.6 kg
Case Size:
Dimensions (H x W x D): 6.5” x 9.5” x 14.0”
Operational Details:
Input Range: 105-125/210-250 VAC (selectable), 50-60 Hz; output is reduced below 110 and 220 VAC.
Operating Temperature for C.D. Units: - 0-65 degrees C, with linear derating from 100% at 50 degrees C to 50% at 65 degrees C, thermal shutdown at 85 degrees C case temperature.
Duty Cycle:
Intermittent: 20 minutes max on time, 20% duty cycle
Continuous: 24 hours/day at 100% duty cycle
Options:
Configure as a battery charger
Adjust output voltage (12.6-14.5 VDC)
Transfer relay for backup battery during power failure (ERC option)
Excellent regulation and ripple specification (output voltage maintained within 1% under all rated line and load conditions)
Corrosion-resistant aluminum case with integral shock mounts for durability
Large heat sink fins ensure cool operation by dissipating heat
Comprehensive protection features: overvoltage, current limit, thermal overload, and input/output fusing
