The Waber-by-Tripp Lite 602 Power Strip offers a convenient method of power distribution in workbench, wallmount or floor mount applications. Includes 5 NEMA 5-15R output receptacles with 1.188-inch center-to-center spacing, 6-ft. (1.83 m) AC line cord and keyhole mounting tabs for installation in a wide variety of applications. Corded, multi-outlet strip reduces cable clutter and enables the connection of multiple electrical devices to a single AC wall socket. Unfiltered electrical pass-through makes the 602 ideal for distributing alternate waveform UPS or generator power. Features rugged all-metal housing, 15-amp resettable circuit breaker and attractive blue/gray color scheme.PLUG/OUTLETS - Input: NEMA 5-15P/Output: 5 NEMA 5-15RELECTRICAL - 120VAC, 50/60Hz, 15A (Requires standard NEMA 5-15R wall receptacle)FORMAT - Corded power distribution strip

• UPC Code: 037332108937
• Nominal Input Voltage(s) Supported: 120V AC
• Recommended Electrical Service: 15A 120V
• Voltage Compatibility (VAC): 120
• Input Plug Type: NEMA 5-15P
• Input Cord Length (ft.): 6
• Right-Angle Plug: No
• Frequency Compatibility: 50 / 60 Hz
• Output Receptacles: (5) 5-15R
• Circuit Breaker (amps): 15
• Transformer Accommodation: (2) Yes
• Outlet Orientation: Single row of 5
• Outlet Spacing: 1.188 in.
• Switches: No power switch
• Color: Gray
• Material of Construction: Metal
• Power Cord Color: Black
• Housing Color: Blue; Gray
• Mounting Holes or Slots: Yes
• Slot or Hole Mount Measurement (Center to Center): Distance between keyhole tabs = 127mm; Distance between end tabs = 207.45
• Outlets Measurement (Center to Center): 1.18 in.
• Receptacle Color: Black
• Shipping Dimensions (hwd / in.): 2.00 x 5.30 x 9.80
• Shipping Weight (lbs.): 1.60
• Unit Dimensions (hwd / in.): 1.500 x 8.750 x 2.500
• Outlet Spacing: 1.188 in.
• Mounting Details: Includes flanges
• Built-In Circuit Breaker: Yes
• Product Certifications: cUL Listed; UL 1363; UL Listed
• Product Compliance: RoHS
• Product Warranty Period (Worldwide): Lifetime limited warranty

Intended Application
Home/Office Industrial/Factory Floor

OUTPUT
Frequency compatibility:50 / 60 Hz
Circuit Breaker (amps):15
Outlet quantity / type:5 NEMA 5-15R
Outlet spacing:1.188 in.
Outlet orientation:Single row of 5 INPUT
Nominal Input Voltage(s) Supported:120V AC
Recommended Electrical Service:15A 120V
Input connection type:NEMA 5-15P
Input cord length (ft.):6
Input cord length (m):1.8288
Voltage compatibility (VAC):120 LEDS ALARMS and SWITCHES
Switches:No switch

Material of construction:
Metal

Integrated keyhole mounting tabs:
Keyhole mounting tabs enable mounting to a variety of surfaces

Receptacle Color:
Black AC line cord color:
Black

Style:
Strip

Outlets center to center measurement:
30mm

Keyhole slot center to center measurement:
Distance between keyhole tabs equal 127mm Distance between end tabs equal 207.45 CERTIFICATIONS
UL1363 (Power Tap):UL1363
cUL / CSA (Canada):cUL Item Dimension (L"xW"xH"):
7.38 x 2.5 x 1.5

Weight:
1.6 lb

Warranty Information:
Lifetime limited
